• G.hn 2Gbps Coax MDU Master Bridge

    Model : CEM-839 / CEM-8392

    Coax MDU Master Bridge
    With In-Building Coax
    Last Meters Distribution
    Providing a Managed
    2Gbps / 1.6Gbps
    Ultra High Speed Service

    Triple Play by QoS and IPv6 Support
    High Throughput Ideally for IPTV Service
    The Most Powerful and Cost-Effective Coax MDU Solution with Remote Management.

    Introduction

    THE COAX MDU MASTER, CEM-839/8392, ENABLES CABLE OPERATORS TO START THE TRIPLE-PLAY SERVICES TO A BUILDING OR COAX SEGMENT.

    NO ADDITIONAL NETWORK WIRING IS NECESSARY. CABLE OPERATORS MAY JUST USE THE EXISTING COAX WIRING OF CABLE OPERATORS OR IN THE MDU BUILDING, THEN BE READY TO PROVIDE THE BROADBAND TRIPLE-PLAY SERVICES TO SUBSCRIBERS.

    LOW INITIAL DEPLOYMENT COST. THE LOW INITIAL COST CAN EXPAND THE SERVICE TO SMALL SCALE BUILDING WITH HIGHER SPEED THAN CMTS. DUAL SUPPORT OF IPV4 AND IPV6 PROVIDE THE FLEXIBILITY FOR OPERATORS.

    WITH CEM-839/8392 HIGH THROUGHPUT AND QOS, IT CAN OPTIMIZE IPTV SERVICE.

    AUTO PROVISIONING AND REMOTE MANAGEMENT. IT MINIMIZES THE INSTALLATION AND SUPPORT COST.

    THE UNIQUE ENDPOINT SERVICE CONTROL SUPPORTS SERVICE PROVIDERS WITH DIFFERENT SERVICE LEVELS AND SERVICE SCHEMES.

    Features

    • Design for Operators Providing High Speed Service over Coax Network
    • EoC up to 2Gbps/1.6Gbps PHY/Throughput Rate as Distribution Backbone over Coax
    • Two 100/1000M Gigabit Ethernet Ports with One Port 100/1000Mbps SFP Support
    • Up to 80dB Attenuation on Coax Network
    • Support up to 16 Endpoints with Isolation for CEM-839
    • Support up to 32 Endpoints with Isolation for CEM-8392
    • Line Power Feeding by Coax or PoE
    • IPv4 and IPv6 Support
    • Endpoint Service Control and Bandwidth Control
    • Endpoint Ethernet Loop Detection and Isolation
    • Online Diagnosis Support
    • DSCP/ToS/802.1p QoS and 802.1Q Tag VLAN Support
    • IGMP Snooping Control
